Mitsubishi LM-K2P2E-12M-1SS1 Electric Linear Actuator LMK2P2E12M1SS1

$5,000.00

AVAILABILITY: Generally allow 7-10 days to ship

Mitsubishi LM-K2P2E-12M-1SS1 Electric linear actuator / servo motor primary side (coil only) with built-in thermistor – core type – Mitsubishi Electric (MELSERVO J4 – LM-K2 series) – Rated current 19A – continuous thrust 1200N / max. thrust 3000N – Rated linear encode speed 2m/s – H74.5mm x W79.2mm x D592mm – compatible with LM-K2S[]-1SS1 magnet – rated for 0…+40°C ambient – equivalent to LMK2P2E12M1SS1

Request a quote for this part+1 714-386-9806
SKU: LM-K2P2E-12M-1SS1 Category: Tag: Brand:
  • Same-day shipping on in-stock items ordered by 4:00 PM Eastern
  • 2-year warranty on most products

Description

Mitsubishi LM-K2P2E-12M-1SS1 Electric Linear Actuator LMK2P2E12M1SS1

  • Extended Product  Type: Linear Actuator
  • Product ID: LM-K2P2E-12M-1SS1
  • Mitsubishi Type Designation: Linear Actuator

Definition of Mitsubishi LM-K2P2E-12M-1SS1 Electric Linear Actuator

Mitsubishi LM-K2P2E-12M-1SS1 Electric linear actuator / servo motor primary side (coil only) with built-in thermistor – core type – Mitsubishi Electric (MELSERVO J4 – LM-K2 series) – Rated current 19A – continuous thrust 1200N / max. thrust 3000N – Rated linear encode speed 2m/s – H74.5mm x W79.2mm x D592mm – compatible with LM-K2S[]-1SS1 magnet – rated for 0…+40°C ambient – equivalent to LMK2P2E12M1SS1

Specification of Mitsubishi LM-K2P2E-12M-1SS1 Electric Linear Actuator

  • Primary brand: Mitsubishi Electric
  • Main function: Electric linear actuator (Coil)
  • Product series / family name: Industrial automation > Drive products > Servo systems > Electric linear actuators > MELSERVO J4 series
  • Sub-range name: MELSERVO J4 – LM-K2 series
  • Functions: Electric linear actuator / servo meter primary side (coil only)
  • Design: built-in thermistor, core type, natural cooling
  • Rated current: 19A, 65A (max. current)
  • Rated power: 7500VA
  • Speed: 2m/s
  • Ambient air temperature for operation: 0…+40 °C
  • Ambient air temperature for storage: -15°C…+70 °C
  • Mechanical resistance: 3000
  • Force: continuous thrust 1200N, max. thrust 3000N
  • Technical compatibility with: LM-H3S[]-CSS0 magnet
  • Order code / Manufacturer SKU: LM-K2P2E-12M-1SS1
  • Manufacturer product status: Commercialized
  • Equivalent to: LMK2P2E12M1SS1
  • Manufacturer description: Primary coil MR-J4 Linear Servo
  • Compliant with standard(s): CE marking, TUV Rheinland, cULus, UL, KC, DIN VDE0580, EN50581, UL1004-6, CSA, EAC
Recommended accessories: for standard 1-axis use amplifiers – MR-J4-500GF – MR-J4-500GF-RJ – MR-J4-500B – MR-J4-500B-RJ – MR-J4-500A – MR-J4-500A-RJ Use amplifier <=> motor cables as follows compatible with Secondary side magnet () (LM-K2S20-384-1SS1) (LM-K2S20-480-1SS1) (LM-K2S20-768-1SS1)

Additional information

Weight 6 lbs
Dimensions 10 × 6 × 8 in
